Send MessageTOP224PN
700V|Isolated|30W
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
IC OFFLINE SWIT PWM OCP HV 8DIP
Specifications
- Brand
- Power Integrations
- Package
- 8-DIP (0.300", 7.62mm)
- Packaging
- —
- Weight
- —
Total Inventory
2,204pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how TOP224PN from Power Integrations fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | Power Integrations | |
| Series | TOPSwitch®-II | |
| Output Isolation | Isolated | |
| Internal Switch(s) | Yes | |
| Voltage - Breakdown | 700V | |
| Topology | Boost, Buck, Flyback, Forward | |
| Voltage - Start Up | - | |
| Voltage - Supply (Vcc/Vdd) | - | |
| Duty Cycle | 67% | |
| Frequency - Switching | 100kHz | |
| Power (Watts) | 30W | |
| Fault Protection | Current Limiting, Over Temperature | |
| Control Features | - | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-DIP | |
| Mounting Type | Through Hole |
