Send MessageS1M-13-F
1000V|1A
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
DIODE GEN PURP 1KV 1A SMA
Specifications
- Brand
- Diodes Incorporated
- Package
- DO-214AC, SMA
- Packaging
- —
- Weight
- —
Total Inventory
1,633,044pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how S1M-13-F from Diodes Incorporated fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | Diodes Incorporated | |
| Series | - | |
| Diode Type | Standard | |
| Voltage - DC Reverse (Vr) (Max) | 1000V | |
| Current - Average Rectified (Io) | 1A | |
| Voltage - Forward (Vf) (Max) @ If | 1.1V @ 1A | |
| Speed | Standard Recovery >500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 3µs | |
| Current - Reverse Leakage @ Vr | 5µA @ 1000V | |
| Capacitance @ Vr, F | 10pF @ 4V, 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AC, SMA | |
| Supplier Device Package | SMA | |
| Operating Temperature - Junction | -65°C ~ 150°C |
