Send MessageL7815CV-DG
35V|1.5A
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
IC REG LINEAR 15V 1.5A TO220
Specifications
- Brand
- STMicroelectronics
- Package
- TO-220-3
- Packaging
- —
- Weight
- —
Total Inventory
439pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how L7815CV-DG from STMicroelectronics fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | STMicroelectronics | |
| Series | - | |
| Output Configuration | Positive | |
| Output Type | Fixed | |
| Number of Regulators | 1 | |
| Voltage - Input (Max) | 35V | |
| Voltage - Output (Min/Fixed) | 15V | |
| Voltage - Output (Max) | - | |
| Voltage Dropout (Max) | 2V @ 1A (Typ) | |
| Current - Output | 1.5A | |
| Current - Quiescent (Iq) | 8mA | |
| Current - Supply (Max) | - | |
| PSRR | 54dB (120Hz) | |
| Control Features | - | |
| Protection Features | Over Temperature, Short Circuit | |
| Operating Temperature | 0°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220 |
