Send MessageESDR0502NMUTBG
5.5V (Max)|-|100W
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
TVS DIODE 5.5V 6UDFN
Specifications
- Brand
- ON Semiconductor
- Package
- 6-UFDFN
- Packaging
- —
- Weight
- —
Total Inventory
4,124pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how ESDR0502NMUTBG from ON Semiconductor fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | ON Semiconductor | |
| Series | - | |
| Type | Steering (Rail to Rail) | |
| Unidirectional Channels | 3 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) | |
| Voltage - Breakdown (Min) | 6V | |
| Voltage - Clamping (Max) @ Ipp | - | |
| Current - Peak Pulse (10/1000µs) | - | |
| Power - Peak Pulse | 100W | |
| Power Line Protection | Yes | |
| Applications | Ethernet | |
| Capacitance @ Frequency | 0.3pF @ 1MHz | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-UFDFN | |
| Supplier Device Package | 6-UDFN (1.2x1) |
