Send MessageDM74LS05N
4.75V ~ 5.25V|-
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
IC INVERTER 6CH 1-INP 14DIP
Specifications
- Brand
- ON Semiconductor
- Package
- 14-PDIP
- Packaging
- —
- Weight
- —
Total Inventory
349pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how DM74LS05N from ON Semiconductor fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | ON Semiconductor | |
| Series | 74LS | |
| Logic Type | Inverter | |
| Number of Circuits | 6 | |
| Number of Inputs | 1 | |
| Features | Open Collector | |
| Voltage - Supply | 4.75V ~ 5.25V | |
| Current - Quiescent (Max) | - | |
| Current - Output High, Low | -, 8mA | |
| Logic Level - Low | 0.8V | |
| Logic Level - High | 2V | |
| Max Propagation Delay @ V, Max CL | 45ns @ 5V, 50pF | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Through Hole | |
| Supplier Device Package | 14-PDIP | |
| Package / Case | 14-DIP (0.300", 7.62mm) |
