Send MessageCNY75B
5000Vrms|100% @ 10mA
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
OPTOISO 5KV TRANS W/BASE 6DIP
Specifications
- Brand
- Vishay Semiconductor Opto Division
- Package
- 6-DIP (0.300", 7.62mm)
- Packaging
- —
- Weight
- —
Total Inventory
100pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how CNY75B from Vishay Semiconductor Opto Division fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | Vishay Semiconductor Opto Division | |
| Series | - | |
| Number of Channels | 1 | |
| Voltage - Isolation | 5000Vrms | |
| Current Transfer Ratio (Min) | 100% @ 10mA | |
| Current Transfer Ratio (Max) | 200% @ 10mA | |
| Turn On / Turn Off Time (Typ) | 5.5µs, 4µs | |
| Rise / Fall Time (Typ) | 3µs, 3.7µs | |
| Input Type | DC | |
| Output Type | Transistor with Base | |
| Voltage - Output (Max) | 70V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.25V | |
| Current - DC Forward (If) (Max) | 60mA | |
| Vce Saturation (Max) | 300mV | |
| Operating Temperature | -55°C ~ 110°C | |
| Mounting Type | Through Hole | |
| Package / Case | 6-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 6-DIP |
