Send MessageBC560CTA
45V|100mA|500mW
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
TRANS PNP 45V 0.1A TO-92
Specifications
- Brand
- Fairchild/ON Semiconductor
- Package
- TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Packaging
- —
- Weight
- —
Total Inventory
44,592pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how BC560CTA from Fairchild/ON Semiconductor fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | Fairchild/ON Semiconductor | |
| Series | - | |
| Transistor Type | PNP | |
| Current - Collector (Ic) (Max) | 100mA | |
| Voltage - Collector Emitter Breakdown (Max) | 45V | |
| Vce Saturation (Max) @ Ib, Ic | 650mV @ 5mA, 100mA | |
| Current - Collector Cutoff (Max) | 15nA (ICBO) | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 420 @ 2mA, 5V | |
| Power - Max | 500mW | |
| Frequency - Transition | 150MHz | |
| Operating Temperature | 150°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) (Formed Leads) | |
| Supplier Device Package | TO-92-3 |
