Send MessageBAT43WS-7-F
30V|200mA (DC)
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
DIODE SCHOTTKY 30V 200MA SOD323
Specifications
- Brand
- Diodes Incorporated
- Package
- SC-76, SOD-323
- Packaging
- —
- Weight
- —
Total Inventory
120,973pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how BAT43WS-7-F from Diodes Incorporated fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | Diodes Incorporated | |
| Series | - | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 30V | |
| Current - Average Rectified (Io) | 200mA (DC) | |
| Voltage - Forward (Vf) (Max) @ If | 1V @ 200mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | 5ns | |
| Current - Reverse Leakage @ Vr | 500nA @ 25V | |
| Capacitance @ Vr, F | 10pF @ 1V, 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-76, SOD-323 | |
| Supplier Device Package | SOD-323 | |
| Operating Temperature - Junction | -55°C ~ 125°C |
Recommended Products
RES 2.49 OHM 0.5% 1W 2512
RES SMD 7.15OHM 0.25% 1/16W 0402
CAP CER 560PF 50V NP0 0805
IC REG BUCK ADJ 1.5A DL 12QFN
MOD PHASE CONTROL SSR 10A 120VAC
CONN HEADR BRKWAY .100 05POS R/A
CONN RCPT HSNG MALE 37POS PNL MT
CONN RCPT HSG MALE 53POS PNL MT
CONN BACKSHELL BANDING 25J OLIVE
CONN EDGE DUAL FMALE 18POS 0.050
Datasheet & Documents
bat43ws-7.pdf
PDF Document · 4 pages
