Send Message74HC4066D
2V ~ 12V|100nA
OriginalGlobal SourcingFast DeliveryQuality CertifiedTechnical SupportBulk Discount
IC SWITCH QUAD 14SOIC
Specifications
- Brand
- Toshiba Semiconductor and Storage
- Package
- 14-SOIC (0.154", 3.90mm Width)
- Packaging
- —
- Weight
- —
Total Inventory
467pcs
Ship within 8 hours
MOQ: 1 pcs
Certifications & Authorizations
Product Video
Discover how 74HC4066D from Toshiba Semiconductor and Storage fits into your design. Our component experts walk through key specifications, quality certifications, and typical application scenarios.
- Authentic sourcing with full traceability
- Rigorous incoming quality inspection
- Competitive pricing & global fast delivery
- Dedicated application engineering support
Technical Specifications
| Manufacturer | Toshiba Semiconductor and Storage | |
| Series | - | |
| Switch Circuit | - | |
| Multiplexer/Demultiplexer Circuit | 1:1 | |
| Number of Circuits | 4 | |
| On-State Resistance (Max) | 80Ohm | |
| Channel-to-Channel Matching (ΔRon) | 5Ohm (Typ) | |
| Voltage - Supply, Single (V+) | 2V ~ 12V | |
| Voltage - Supply, Dual (V±) | - | |
| Switch Time (Ton, Toff) (Max) | 12ns, 12ns | |
| -3db Bandwidth | 200MHz | |
| Charge Injection | - | |
| Channel Capacitance (CS(off), CD(off)) | 3pF | |
| Current - Leakage (IS(off)) (Max) | 100nA | |
| Crosstalk | -60dB @ 1MHz | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 14-SOIC |
